Features

• Suitable for standard rigid metal conduit and schedule 40 rigid PVC conduit only
• Pemanently fastened to support ring
• For permanent support when cable end is available to be installed through the grip
• Split Mesh- Rod Closing

Specifications

• Country of Origin: United States
• Approx Breaking Strength: 2,670 lb.
• Cable Diameter Range: 2 in- 2.49 in
• Conduit Trade Size: 4 in
• Width: 3.800 in
• Each - Width: 3.800 in
• Industry Standard(s): CSA Certified
• Performance: Mechanical - Approximate Breaking Strength - 2,670 (11,876)
• Application: Cable Support in Conduit
• Cable Size: 2.00"-2.49" (5.08-6.32)
• Special Features: Split Mesh- Rod Closing
• Standard: CSA Certified
• Type: Ring Type
• Style: Split Mesh, Rod Closing, Single Weave
• Class Code: A52
• Description - Invoice: COND RISER, 2.0-2.5"; 4" COND, ROD
• Freight Class Code: 06168002
• Harmonization Code: 7419805050
• Image Actual Or Representative: A
• MSDS Flag: No
• Sub Class Code: A52A480
• Material - Mounting Hardware: Mounts Inside Conduit
• Construction: Woven
• Material: Bronze, Tin Coated
• Series: Conduit Riser
• Base Unit of Measure: EA
• Carton - SCC-14 Next Lower Level Sub Pack: 00783585307060
• Each - Pack Description: Each
• Lowest Level UOM: Each

Certifications

• EU RoHS Indicator: Yes
