Description
Features
- 72 trippers provide 36 ON/OFF events per 24-hour period
- Captive trippers with 20-minute switching intervals
- 3-way (SPDT) switch available
- 3-position ON/OFF/AUTO override provides continuous ON or OFF operation
- Reliable synchronous timer motor
- Multiple wall plates available
- Easy wiring and installation
- Heavy-Duty 20 A rating
- Requires neutral connection
Prop 65
- Please see the Warning @ www.P65Warnings.ca.gov - DEHP
Specifications
- Country of Origin: Mexico
- Operating Temperature Min: -40°F; -40°C
- Operating Temperature Max: 180°F; 82°C
- Warranty Period: 1-Year limited
- Minimum On Off Time: 20 min
- In Wall Wiring Configurations: Single
- Maximum On Off Operations: 36
- Operation Mode: 24 hour
- Operating Humidity: 0 to 95%, Non-condensing
- Color: White
- Applications: Indoor Lighting Control; Air Movement & Ventilation; Outdoor Lighting Control
- Application Compatibilities: Incandescent; Fluorescent; CFL
- Wall Plate Configuration: 3-Gang
- Wiring Option: SPST (3) #14 AWG color coded; SPDT (4) #14 AWG color coded
- Input Voltage Ranges: 120 VAC, 60 Hz
- Mechanism Type: Analog/Mechanical
- Switch Type: SPST
- Incandescent Multi Gang Load Ratings Ranges: 1350 W, 120 VAC, 60 Hz
- Includes Wall Plate CVL: Yes
- PDF Standards And Certifications: cULus; cCSAus
Certifications
- UL Certification: cULus
- CSA Certification: cCSAus
Load Ratings
- Incandescent Multi Gang Load Ratings: 1350 W, 120 VAC, 60 Hz
- Resistive Load Ratings: 20 A, 120 VAC, 60 Hz
- Inductive Load Ratings: 8 A, 120 VAC, 60 Hz
- Inductive Load Ratings Ranges: 8 A, 120 VAC, 60 Hz
- Motor Load Ratings Ranges: 1 HP, 120 VAC, 60 Hz
