Features

• Versatile, general-purpose floodlight
• 7H x 7V NEMA distribution
• 0-10V dimming
• IP65 rating protects against dust and water
• 50,000-Hour LED lifespan
• 5 Yr Limited Warranty
• Trade Agreements Act Compliant
• Buy American Act Compliance

Specifications

• Weight: 10.8 lbs

Compliance

• UL Listed: Suitable for wet locations. Suitable for ground mounting.
• IESNA LM-79 & LM-80 Testing: RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.
• DLC Listed: This product is listed by Design Lights Consortium (DLC) as an ultra-efficient premium product that qualifies for the highest tier of rebates from DLC Member Utilities. Designed to meet DLC 5.1 requirements.

Performance

• Watts: 160W
• Color Temp: 5000K (Cool)
• Lumens: 20,945 lm
• Efficacy: 141 lm/W
• Color Accuracy: 82 CRI
• Type: Constant Current
• 120V: 1.26A
• 208V: 0.77A
• 240V: 0.67A
• 277V: 0.56A
• Input Watts: 148W

LED Characteristics

• LEDs: Long-life, high-efficacy, surface-mount LEDs
• Color Uniformity: RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017.

Construction

• IP Rating: Ingress protection rating of IP65 for dust and water
• EPA: 1.2
• Cold Weather Starting: The minimum starting temperature is -40°C (-40°F)
• Maximum Ambient Temperature: Suitable for use in up to 40°C (104°F)
• Housing: Precision die-cast aluminum
• Mounting: Slipfitter with tilt angle in 10° increments
• Lens: Tempered glass
• Finish: Formulated for high durability and long-lasting color
• Green Technology: Mercury and UV free. RoHS-compliant components.
• Tilt Increment: Rotates in 6 degree increments

Electrical

• Driver: Constant Current, 120-277V, 50/60 Hz, 120V: 1.26A, 208V: 0.77A, 240V: 0.67A, 277V: 0.56A
• Dimming Driver: Driver includes wiring for 0-10V dimming systems. Dim as low as 10%.
• THD: 4.67% at 120V, 5.43% at 277V
• Power Factor: 99.8% at 120V, 96.6% at 277V
• Note: All values are typical (tolerance +/- 10%)
