Description
Features
- Movable Neutrals and Grounds
- Pivoting Rain Gutter
- Removable Back Plate
- REACH Compliant
- Made in USA
Additional Information
- Number of Cutout 6
- Cutout Size 1, 1-1/4, 1-1/2, 2
- Cable Entry Bottom Feed
- Terminal Quick Connect, Insulated, Mounting Rail
- Application Garden-Style, Meter Rise, High Rise
- Approval UL 67
Specifications
- Breaker Type: QS/QSH/QSHH/HQS/HQSH/QP/QPH/HQP/MP-T/MP-HT/MP-MT
- Voltage Rating: 120/240 Volt AC
- Circuit Configuration: 1-Phase 3-Wire (Incoming/Outgoing)
- Bus Current Rating: 1200 Amp
- Number of Sockets: 4
- Socket Current Rating: 225 Amp
- Socket Cover Style: Ring
- Number of Jaws: 5
- Size: 16.222 Inch Width x 8.09 Inch Depth x 52.31 Inch Height
- Application: Residential
Downloads
Specification/TechnicalCatalog
Data Sheet
Installation/Operator
CAD Drawing
More Information
Manufacturer Catalog Number
WMM41225J
Weight
62.8000
Applications
Residential
Product Size
16.222 inches
Voltage
120/240 volts
