Description
Features
Additional Information
- RoHS Compliant
- Jacket Thickness 0.006 Inch
- Insulation Thickness 0.04 Inch
- Applicable Standard ICEA S-95-658/NEMA WC70, NEC 310
Specifications
- Type: THHN
- Voltage Rating: 600 V
- Current Rating: 70 Ampere (60 Deg C), 85 Ampere (75 Deg C), 95 Ampere (90 Deg C)
- Conductor Material: Annealed Bare Copper
- Conductor Size: 4 AWG
- Stranding: 19 Strands
- Jacket Material: Nylon
- Insulation Material: PVC
- Insulation Color: Brown
- Outer Diameter: 0.322 Inch
- Length: 5000 Ft
- Temperature Rating: 90 Deg C (Dry/Wet)
- Weight: 159 Lb/Mft
- Package Type: Reel
- Approval: UL 83, CUL
More Information
Manufacturer Catalog Number
THHN-4-BRN-19STR-CU-MASTER
Weight
0.160161
Length
Cut to Length
Color
Brown
Conductor Material
Copper
Conductor Size
4
Current
60 degrees celsius
Strands
Stranded
Voltage
600 volts
Wire Color
Brown
