Features

• THHN/THWN-2 High Speed Cable is a Versatile Solution for Most General Wiring Applications, from Service Entrance and Feeders to Branch Circuits
• Low Friction Nylon Jacket Provides Easy Pulling for 8 AWG and Larger
• 1/0 AWG and Larger are Rated for Cable Tray Use
• Rated Gasoline and Oil-Resistant II
• Resistant to Abrasion, Acids, Alkalines, Ozone and Water
• For THHN Applications, the Conductor is Appropriate for Use in Dry Locations not to Exceed 90 Deg C

Additional Information

• RoHS Compliant
• Jacket Thickness 0.004 Inch
• Insulation Thickness 0.015 Inch
• Applicable Standard ICEA S-95-658/NEMA WC70, NEC 310

Specifications

• Type: THHN
• Voltage Rating: 600 V
• Current Rating: 15 Ampere (60/75/90 Deg C)
• Conductor Material: Solid Plain Copper
• Conductor Size: 14 AWG
• Stranding: Solid
• Jacket Material: Nylon
• Insulation Material: PVC
• Insulation Color: Orange
• Outer Diameter: 0.104 Inch
• Length: 500 Ft
• Temperature Rating: 90 Deg C (Dry), 75 Deg C (Wet)
• Weight: 17 Lb/Mft
• Package Type: Reel/Spool
• Approval: UL 83, CUL
