- Bonding Wire Size 16 AWG Solid (Aluminum)
- Application Branch, Feeder and Service Power Distribution, Power, Lighting, Control, Signal Circuits and Dry Location
Specifications
- Type: AC
- Voltage Rating: 600 V
- Current Rating: 20 Ampere
- Conductor Material: Soft Drawn Copper
- Conductor Size: 12 AWG
- Number of Conductors: 2
- Stranding: Solid
- Armor Material: Lightweight Aluminum
- Insulation Material: THHN
- Color Code: Black/White
- Outer Diameter: 0.498 Inch
- Length: 250 Ft
- Temperature Rating: 90 Deg C
- Weight: 107 Lb/MFt
- Package Type: Coil
- Approval: UL 4/83
More Information
Manufacturer Catalog Number
AC-AL-12/2-SOL-90D-CU-250CL
Weight
0.107
Length
250
Conductor Material
Copper
Conductor Size
12
Current
20 amperes
Strands
Solid
Voltage
600 volts
Wire Color
Black/White
Wire Length
250
Wire Size
12
