Specifications

North American Specifications (UNSPSC)

• UNSPSC: 39121310 Utility boxes
• IGCC: 4440 Utility boxes
• Brand Name: Steel City
• Type: Utility Boxes
• Special Features: Factory provided raised ground screw location.
• Application: For use with conduit
• Standard: UL E2969
• Number Of Outlet: 1
• Material: Steel
• Size: 4 Inches Length x 2-1/8 Inches Width x 2-1/8 Inches Depth
• Color: Silver
• Construction: Drawn
• Cubic Capacity: 14.5 Cubic Inches
• Knockouts: 7

European Specifications (ETIM)

• ETIM: EC000080 Surface mounted housing for flush mounted switching device
• Assembly arrangement: Surface mounted housing
• Mounting direction: Vertical
• Material: Metal
• Colour: Silver
• Transparent: N
• Width of device: 53.975mm

Packaging

• Outer Quantity: 25
• Outer Dimensions (inches): 16.7x11x4.5
• Weight Uom: 65.38 lbs. per 100
