Specifications

• UPC Code: 78366964385
• UNSPSC Code: 39121448
• Dual Rated: FALSE
• Conductor Range CU Stranded (Primary, run, main, line): 350 kcmil
• Conductor Size CU (Primary, run, main, line): 350 kcmil
• Flex Conductor Range: 250 I,K,M 262.2 DLO
• Flex Conductor Size (Class I): 250 I
• Flex Conductor Size (Class K): 250 K
• Flex Conductor Size (Class M): 250 M
• Flex Conductor Size (Class DLO): 262.2 DLO
• Expanded Conductor Range: 350 kcmil - 3/0 Str
• Expanded Conductor Size: 350 kcmil,300 kcmil,250 kcmil,4/0 Str,3/0 Str
• Mounting Bolt/Stud Size: 1/2/2020
• Length (IN): 4.186
• Length (mm): 106.3244
• Width (IN): 1.291
• Width (mm): 32.7914
• Height (IN): 0.929
• Height (mm): 23.5966
• Weight (LB): 0.280921735
• Barrel Length (IN): 1.063
• Barrel Length (mm): 27.0002
• Dimension G (IN): 0.546
• Dimension G (mm): 13.8684
• Inside Diameter (IN): 0.703
• Inside Diameter (mm): 17.8562
• Mounting Bolt/Stud Size (mm): 304.8
• Mounting Hole Diameter (IN): 0.562
• Mounting Hole Diameter (mm): 14.2748
• Mounting Hole Spacing (IN): 1.25
• Mounting Hole Spacing (mm): 31.75
• Outside Diameter (IN): 0.889
• Outside Diameter (mm): 22.5806
• Strip Length (mm): 28.575
• Tang Length (IN): 2.5
• Tang Length (mm): 63.5
• Tang Thickness (IN): 0.187
• Tang Thickness (mm): 4.7498
• Tang Width (IN): 1.291
• Tang Width (mm): 32.7914
• Material: Copper
• Conductor Material: Copper
• Connector Finish: Tin
• Color: Silver
• Die Color Code: Red
• Direct Burial: TRUE
• Temperature Rating: 90°C
• Voltage Rating: 35 kV
• CSA File Number: LR-29601
• CSA Standard: C22.2 No. 65-03
• UL Control Number: 453G
• UL File Number: E6207
• UL / CULUS Specification: UL 486A/B Listed,UL 467 Listed
• NEBS Rating: Level 3
• Prop65 Compliance: This product is in compliance with Prop65. It is not known to contain any chemicals associated with this regulation
• Barrel Marking: Ink
• Barrel Type: Standard
• Connection: Compression
• Connecting angle: 180°
• Conductor Type: Stranded,Flex
• Contains DE-OX: FALSE
• ILSCOs Die Catalog Number: ILD-71
• Flared End: FALSE
• Mounting Hole Type: Thru
• Narrow Tang: FALSE
• Number of Mounting Holes: 2
• Sight Window: TRUE
• Slotted: FALSE
• Tang End Shape: Square
• Undrilled: FALSE
• Bag Quantity: 1
• CrossSell: ILD-71, DE-OX-8OZ, TB-6DF1000-P
