Specifications

• Height: 0.597 in | 15.1638 mm
• Length: 2.771 in | 70.3834 mm
• Weight: 0.0790434634454263 lbs
• Width: 0.562 in | 14.2748 mm

Additional Technical Specifications

• Conductor Type: Stranded, Flex

Additional Class Attributes

• Barrel Marking: Ink
• Barrel Type: Long
• Connecting Angle: 180°
• Connection: Compression
• Contains DE-OX®: No
• Flared End: No
• ILSCOs Die Catalog Number: ILD-45
• ILSCOs Die Index Number: I-45
• Mounting Hole Type: Thru
• Narrow Tang: Yes
• Number of Mounting Holes: 1
• Sight Window: Yes
• Slotted: No
• Tang End Shape: Square
• Undrilled: No

Material and Finish

• Conductor Material: Copper
• Connector Finish: Tin
• Material: Copper

Bolt and Screw Sizes

• Mounting Bolt/Stud Size: #10

Environment and Temperature

• Temperature Rating: 90°C

Conductor Ranges

• Conductor Range CU Stranded (Primary, run, main, line): 2/0 Str
• Expanded Conductor Range: 2/0 Str - 4 Str
• Flex Conductor Range: 1/0 G,H,I,K,M,DLO

Color

• Color: Silver
• Color Code: Black

Voltage

• Voltage Rating: 35 kV

Testing Standards

• CSA File Number: LR-29601
• CSA Standard: C22.2 No. 65-03
• NEBS Rating: Level 3
• Prop65 Compliance: This product is in compliance with Prop65. It is not known to contain any chemicals associated with this regulation
• UL Control Number: 453G
• UL / CULUS Specification: UL 467 Listed, UL 486A/B Listed
• UL File Number: E6207

Dimensions

• Barrel Length (IN): 1.5
• Barrel Length (mm): 38.1
• Dimension G (IN): 0.259
• Dimension G (mm): 6.5786
• Height BX (IN): 2.25
• Height (mm): 15.1638
• Inside Diameter (IN): 0.437
• Inside Diameter (mm): 11.0998
• Length (mm): 70.3834
• Mounting Bolt/Stud Size (mm): 254
• Mounting Hole Diameter (IN): 0.219
• Mounting Hole Diameter (mm): 5.5626
• Mounting Hole Spacing (mm): 0
• Outside Diameter (IN): 0.562
• Outside Diameter (mm): 14.2748
• Strip Length (mm): 20.6375
• Tang Length (IN): 0.875
• Tang Length (mm): 22.225
• Tang Thickness (IN): 0.16
• Tang Thickness (mm): 4.064
• Tang Width (IN): 0.547
• Tang Width (mm): 13.8938
• Weight BX (LB): 1.6327
• Width BX (IN): 5
• Width (mm): 14.2748

General

• Bag Quantity: 1
• Carton Quantity Description: STD PACK QTY 10
• Direct Burial: Yes
• Dual Rated: No
• NEMA Code: S-588-3
• UPC Code: 78366968645
