Specifications

• Height: 1.105 in | 28.067 mm
• Length: 5.125 in | 130.175 mm
• Weight: 0.275 lbs
• Width: 1.105 in | 28.067 mm

Dimensions

• Height BX (IN): 2.25
• Height (mm): 28.067
• Inside Diameter (IN): 0.72
• Inside Diameter (mm): 18.288
• Length (mm): 130.175
• Outside Diameter (IN): 1.105
• Outside Diameter (mm): 28.067
• Weight BX (LB): 0.84
• Width BX (IN): 4.25
• Width (mm): 28.067

Additional Technical Specifications

• Conductor Type: Stranded

Additional Class Attributes

• Barrel Marking: Hard
• Barrel Type: Standard
• Connecting Angle: 180°
• Connection: Compression
• Contains DE-OX®: Yes
• Flared End: No
• ILSCOs Die Index Number: 299
• Number of Conductors: 1
• Sight Window: No
• Slotted: No

Material and Finish

• Conductor Material: Aluminum, Copper
• Connector Finish: Tin
• Material: Aluminum

Environment and Temperature

• Temperature Rating: 90°C

Conductor Ranges

• Conductor Range AL Stranded (Primary, run, main, line): 350 kcmil
• Conductor Range CU Stranded (Primary, run, main, line): 350 kcmil
• Expanded Conductor Range: 350 kcmil - 3/0 Str

Color

• Color: Silver
• Color Code: Brown

Voltage

• Voltage Rating: 35 kV

Testing Standards

• CSA File Number: LR-29601
• CSA Standard: C22.2 No. 65-03
• Prop65 Compliance: This product is in compliance with Prop65. It is not known to contain any chemicals associated with this regulation
• UL Control Number: 453G
• UL / CULUS Specification: UL 486A/B Listed
• UL File Number: E6207

General

• Bag Quantity: 1
• Carton Quantity Description: STD PACK QTY 3
• Dual Rated: Yes
• NEMA Code: S-588-1
• UPC Code: 78366918482
