Features

• Provides protection against UV rays with its ethylene propylene rubber backing
• Primary electrical insulation for cable and wire connections and vibration padding for motor leads rated up to 1000 volts
• Thick construction allows quick application build–up and padding over irregular connections
• Withstands temperatures up to 194 °F (90 °C)
• RoHS 2011/65/EU Compliant

Specifications

• Manufacturer Catalog Number: 7000005986
• Adhesion to Steel: 15.0lb/in (26,2N/10mm)
• Application: Insulation
• Backing Material: Ethylene Propylene Rubber
• Breaking Strength (Imperial): 150 lb.
• Color Family (incorporate Product Color): Black
• Dielectric Strength (V/mil): 500 V/mil
• Elongation: 10 %
• Elongation at Break: 10
• Liner/Linerless: Liner
• Material: EPR with Liner
• Maximum Operating Temperature (Celsius): 90 Degree Celsius
• Maximum Operating Temperature (Fahrenheit): 194 Degree Fahrenheit
• Minimum Operating Temperature (Celsius): 0 Degree Celsius
• Overall Length (Imperial): 10 ft
• Overall Length (Metric): 3 m
• Overall Width (Imperial): 2 in
• Overall Width (Metric): 50.8 mm
• Self-sticking: Yes
• Tape Color: Black
• Tape Width (Imperial): 2 in
• Tape Width (Metric): 50.8 mm
• Total Tape Thickness without Liner (Metric): 1.65 mm
• Total Thickness: 1.65 mm
• UV Resistant: Yes
• Vulcanizing: No

Packaging

• Package Length: 2.75000 in
• Package Height: 4.05000 in
• Package Weight: 0.8850 LBS
