Features

• Cable Supports are Used to Support Cables in Vertical Raceway/Riser
• It Uses a 1-Piece Type S Hardwood Wedging Plug
• Knurled Insulating Inner Surface and 1-Piece Impregnated Hardwood pOZi-grip Plug Provide Positive Support Well in Excess of Code Requirement
• For Supporting Non-Armored Electrical Cables in Vertical Conduit Riser
• The Fastest and Easiest Type Cable Support to Install

Additional Information

• Applicable Standard NEC/CEC

Specifications

• Type: Knurled/Tapered
• Plug Type: 1-Piece
• Conduit Type: IMC/Rigid
• Voltage Rating: 600 Volt AC
• Conduit Position: Vertical
• Conductor Size: 18 to 8 AWG, 6 to 0 AWG, 2/0 to 4/0 AWG, 4/0 AWG to 750 KCMIL (Copper/Aluminum)
• Conduit Size: 4 Inch
• Cable Type: Non-Armored
• Size: 5.63 Outer Diameter x 3.88 Inch Length
• Material: Hot Dip Galvanized Malleable/Ductile Iron
• Application: Commercial, Indoor
• Approval: UL 514B, CSA C22.2
• Series/Model: S
