Features

• Concrete Tight - The hub is perfect for applications where concrete aggregate could abrade conductor insulation or effectively reduce the area inside the raceway
• NPSM Threads - Operators can create a pressure-tight, vibration-resistant seal when the male and female threads are properly connected
• Die Cast Zinc Construction - The die cast zinc body is naturally resistant to corrosion for long-term use in any environment
• Insulated Throat - The hub features an insulated throat that is rated up to 105°C

Certifications and Standards

• UL-514B

Specifications

• Country of Origin: United States
• Length: 2.75 in
• Width: 1.25 in
• Weight: 110.5 lbs
• BPT Trade Size: 2"
• Field Application: To secure threaded rigid service entrance conduit to box or enclosure. Insulated throat rated 105 degree C. UL listed Type 4 - Watertight. Suitable for Aluminum and Steel Rigid Conduit
• FINISH: Ball burnished, mirror smooth
• MATERIAL: Zinc Die Cast
• NEMA Rating: FB-1
• UL File #: E9391
