Features

Certifications

• cULus Listed
• RoHS Compliant
• NAFTA Compliant

• One consistent design: Mix-and-match Resource RFBA Series Floor Boxes of any size with interchangeable components. Makes every project installation quick and efficient.
• Universal sized conduit feed: Meets all requirements for each box. 2- and 4-gang shallow boxes accept a 1”” conduit feed, while all standard boxes accept a 2”” conduit feed.
• Improved wire and cable routing: Allows for easier wire pulling in adjacent compartments and around corners, reducing the overall cost for most cabling requirements.
• Two finishes: Every box configuration is available in either a standard zinc-plated construction or a lightweight ““slab-on-grade”” finish with fusion-bonded epoxy corrosion resistant paint.
• Removable dividers post-pour: Fully adjustable before and after the concrete pour.
• Adapts to most power and communication needs: Common mounting plates can be used for any of the Resource RFB Series Floor Boxes. Reduces overall life cycle cost.

Specifications

• Finish: Pre-Galvanized
• Material: Steel
• Product Line: Wiremold

Specifications

• Depth: 3.0 in
• Width: 16.25 in
• Country of Origin: Mexico
