Features

• 15A-120/277VAC switch for 3-way applications, available in 20 popular colors to match any décor
• Use two 3-way switches to control light(s) from two locations, ideal in hallways and stairways
• Once installed, Renu 3-way switches can be updated to a new color by ordering an RK15X color change kit
• Switch face easily snaps OFF and ON to change color
• To complete the look, snap on a matching or contrasting Renu screwless wallplate (sold separately)
• Turns the electrical device into a decorative, easily updated accessory
• Shallow size is easy to install in any wallbox
• Self-grounded when installed in a properly grounded metal wallbox
• Back, side and quick wired for fast, easy installation
• Terminals designed to withstand high torque and resist wire pullout
• The selection also includes single-pole and 4-way switches
• Use only with Renu wallplates
• NOTE: In Canada, a general-use switch does not require attachment to a grounding/bonding wire when installed in a grounded/bonded flush device box.
• Renu in a snap! Renu is the smart new line of decorative electrical products from Leviton. Install Renu and get a fresh stylish look, plus the ability to change the color of any Renu device when you update a room. The Renu line includes switches, outlets, GFCIs, dimmers, and sleek, screwless wallplates, available in 20 designer colors to blend in or contrast with your decor. All Renu RE153 3-way switches are shallow in size, self-grounded*, and have Quickwire, back, and side wiring options for fast, easy installation. The selection also includes single-pole and 4-way switches. Use only with Renu wallplates. *When installed in a properly grounded metal wallbox.

Color Variations

• Cafe Latte

Specifications

• Country of Origin: China
• RoHS Compliant: True

Product Features

• Actuator Material: Thermoplastic
• Amperage: 15 A
• Body Material: Polycarbonate
• Color: Whispering Wheat
• Color Change Kit: RK15X
• Device Type: Switch
• Feature: 3-Way
• Grounding: Self-Grounding Clip and Green Ground Screw
• HP Rating: 1/2HP-120V 2HP-240V-277V
• Max. Amperage: 15 Amp
• Pole: 3
• Product Family: Renu
• Ratings: 15A-120/277V
• Standards and Certifications: cULus
• Strap Material: Steel
• Switch Type: 3-Way
• Termination: Back, Side & Quickwire
• Torque Range: 14 – 18 in.-lbs
• Type: Electro-Mechanical Switch
• Voltage: 120/277 VAC
• Warranty: 5-Year Limited
