Specifications

• Volume: 0.22 LB
• Height: 1.300 IN
• Volume: 31.843500000000002 CI
• Length: 6.900 IN
• Width: 3.550 IN
• Country of Origin: US
• Diameter: Actual hole size: 1.362'' (34.6 MM)
• Application: For punching conduit sized holes in mild steel, aluminum, fiberglass, and plastic.
• Material: Black Oxide Finish
• Operation: Must be used with other SPEED PUNCH® System components.
• Capacity: Mild steel up through 10 gauge (3.5 mm).
• Driver: Use with Greenlee Hydraulic Drivers - Quick Draw® Flex (7704SB), Quick Draw® Standard (7804SB), QUICK DRAW 90® (7904SB) and Hyraulic Ram (746 W/7212SP12 LONG DRAW STUD), OR LS50 BATTERY-POWERED DRIVER (LS50L11A).
• Sub Brand: SPEED PUNCH®
• Draw Studs: Std. Draw Stud: 7212SP11 (3/4'' x 4.77'') Long Draw Stud: 7212SP12 (3/4'' x 5.63'') - For use with 746 Hydraulic Ram
• Type: Knockout Punches
• Minimum Pilot Hole: Recommended size: 7/8'' (22.2 MM)
