Features

• .036 inch thick, brass, triple-wipe power contacts for lasting retention.
• Illuminated face indicates power to receptacle and makes it easy to identify receptacle in dark applications.
• Built-in connector features large brass terminal blades to ensure consistent, reliable electrical connections.
• Crimped and welded contacts.
• Ultrasonically welded polycarbonate connector housing secures terminations and conductors in a UL Listed, finger safe housing.
• Large brass contacts snugly terminate on device blade terminals.
• Auto-ground clip assures positive ground.
• For covering patents, see www.legrand.us/patents.
• For compatible wall plate options, from our TradeMaster unbreakable plates to our radiant screwless plates to our metal wall plates, click here.
• Temperature Rise: Maximum 30°C temperature rise at full-rated current after 50 cycles of overload at 150% of rated current with direct current. Operating Temperature: Maximum continuous +60°C, minimum -40°C without impact
• PlugTail™ Connector: #12 AWG, THHN, copper conductor, 6"" leads, stripped, solid or stranded, for use with PlugTail Receptacles only

Certifications

• Federal Spec Listed
• cULus Listed

Specifications

• Depth: 0.86 in
• Height: 2.75 in
• Width: 1.625 in
• Country of Origin: Mexico

Specifications

• Color: Red
• Product Line: Pass & Seymour
