Specifications

• Height: 0.822 in
• Length: 1.75 in
• Weight: 0.068 lbs
• Width: 0.659 in

Additional Class Attributes

• ILSCOs Die Index Number: 13

Dimensions

• Height BX (IN): 2.25
• Weight BX (LB): 1.759
• Width BX (IN): 5

Material and Finish

• Conductor Material: Copper
• Connector Finish: Bright Dip
• Material: Copper

Conductor Ranges

• Conductor Range CU Stranded (Primary, run, main, line): 1 Str - 3 Str
• Conductor Range CU Stranded (Secondary, tap, load): 3 Str - 12 Str

Testing Standards

• Prop65 Compliance: This product is in compliance with Prop65. It is not known to contain any chemicals associated with this regulation
• UL / CULUS Specification: UL 486A/B Listed, UL 467 Listed
• UL File Number: E6207

Color

• Color: Copper
• Color Code: Black

Voltage

• Voltage Rating: 35 kV

General

• Bag Quantity: 1
• Carton Quantity Description: STD PACK QTY 25
• Direct Burial: Yes
• NEMA Code: 0-000-1
• UPC Code: 78366968943
