Specifications

• Height: 0.948 in
• Length: 1.75 in
• Weight: 0.085 lbs
• Width: 0.755 in | 19.177 mm

Additional Class Attributes

• ILSCOs Die Index Number: 14

Dimensions

• Height BX (IN): 2.25
• Weight BX (LB): 0.909
• Width BX (IN): 4.375
• Width (mm): 19.177

Material and Finish

• Conductor Material: Copper
• Connector Finish: Bright Dip
• Material: Copper

Conductor Ranges

• Conductor Range CU Solid (Primary, run, main, line): 1/0 Sol - 1 Sol
• Conductor Range CU Solid (Secondary, tap, load): 3 Sol - 12 Sol
• Conductor Range CU Stranded (Primary, run, main, line): 1/0 Str
• Conductor Range CU Stranded (Secondary, tap, load): 4 Str - 12 Str

Testing Standards

• Prop65 Compliance: This product is in compliance with Prop65. It is not known to contain any chemicals associated with this regulation
• ROHS Indicator: IND
• UL / CULUS Specification: UL 467 Listed, UL 486A/B Listed
• UL File Number: E6207

Color

• Color: Copper
• Color Code: Orange

Voltage

• Voltage Rating: 35 kV

General

• Bag Quantity: 1
• Carton Quantity Description: STD PACK QTY 10
• Direct Burial: Yes
• NEMA Code: 0-000-1
• UPC Code: 78366968944
