Specifications

• Height: 0.75 in
• Length: 1.968 in
• Weight: 0.221 lbs
• Width: 0.922 in

Additional Class Attributes

• ILSCOs Die Index Number: 997

Dimensions

• Height BX (IN): 2.25
• Weight BX (LB): 3.3224
• Width BX (IN): 4.375

Additional Technical Specifications

• Conductor Type: Stranded, Solid

Material and Finish

• Conductor Material: Copper
• Connector Finish: Bare
• Material: Copper

Conductor Ranges

• Conductor Range CU Solid (Secondary, tap, load): 2/0 Sol - 6 Sol
• Conductor Range CU Stranded (Primary, run, main, line): 250 kcmil - 3/0 Str
• Conductor Range CU Stranded (Secondary, tap, load): 2/0 Str - 6 Str
• Ground Rod Size: 1/2
• Rebar Size(s) Main: #4 (1/2)
• Rebar Size(s) Secondary: #3 (3/8)

Testing Standards

• Prop65 Compliance: This product is in compliance with Prop65. It is not known to contain any chemicals associated with this regulation
• UL / CULUS Specification: UL 467 Listed

Color

• Color: Copper

General

• Bag Quantity: 1
• Carton Quantity Description: STD PACK QTY 6
• Direct Burial: Yes
• Dual Rated: No
• NEMA Code: S-573-3
• UPC Code: 78366925738
