Specifications

• Height: 1.2 in
• Length: 1.61 in
• Weight: 0.305 lbs
• Width: 0.999 in

Dimensions

• Height BX (IN): 2
• Weight BX (LB): 8.4645
• Width BX (IN): 6.1875

Additional Technical Specifications

• Conductor Type: Stranded

Additional Class Attributes

• Barrel Marking: Hard
• ILSCOs Die Index Number: D3

Material and Finish

• Conductor Material: Copper
• Connector Finish: Bare
• Material: Copper

Environment and Temperature

• Temperature Rating: 90°C

Color

• Color: Copper

Conductor Ranges

• Conductor Range CU Stranded (Primary, run, main, line): 4/0 Str - 3/0 Str
• Conductor Range CU Stranded (Secondary, tap, load): 4/0 Str - 3/0 Str

Voltage

• Voltage Rating: 35 kV

Testing Standards

• CSA File Number: LR-29601
• CSA Standard: C22.2 No. 65-03
• Prop65 Compliance: This product is in compliance with Prop65. It is not known to contain any chemicals associated with this regulation
• ROHS Indicator: IND
• UL Control Number: 453G
• UL / CULUS Specification: UL 467 Listed, UL 486A/B Listed
• UL File Number: E6207

General

• Bag Quantity: 1
• Carton Quantity Description: STD PACK QTY 25
• Direct Burial: Yes
• Dual Rated: No
• NEMA Code: S-588-1
• UPC Code: 78366993083
