Features

• Recommended for the suspension of stationary non-insulated pipe lines
• Easy-to-close clamp for steel pipe and copper tube
• Unique hinged design eliminates the need to disassemble the clamp prior to installation
• Clamp can be closed with one hand, without ever turning a screw
• All-steel design of the closing mechanism retains strength even when exposed to heat
• Comes with a welded 3/8" cap nut, allowing easy attachment to threaded rod
• Combo head bolt works with slotted, hex, or Phillips drivers
• Conforms with Manufacturers Standardization Society (MSS) SP-58 (Type 12)
• Category II noise reduction according to DIN EN ISO 3822-1
• Compliant for sound insulation design according to DIN 4109
• Reaction-to-fire classification is "E" in compliance with DIN EN 13501-1

Specifications

• Weight: 0.07 kilogram
• Material: Steel
• Finish: Electrogalvanized
• Temperature: -50-110.00
• Outer Diameter (OD): 33.4-34.90
• Pipe Size: 1-1.00
• Copper Tube Size: 1.25-1.25
• Rod Size (RS): 0.375
• Rod Size (RS) (inch): 0.375
• Static Load (F): 800
• Sub Brand: CADDY
