Features

• The original smooth linear-slide dimmer
• Over 25 years of proven reliability in the most demanding applications
• Exclusive heat sink design maximizes convection cooling to maximize reliability
• Full family of products for most lighting sources
• Heavy duty components for surge protection and long product life
• Precise color matching across all controls
• Controls 16 A LED driver/3-wire fluorescent ballast loads
• Slide up to brighten, down to dim.

Standards and Certifications

• UL
• CSA
• NOM
• ANSI/IEEE Std. C62.41-1980

Specifications

• Application: Lighting Control
• Environmental Conditions: Indoor use only
• Frequency Rating, Maximum: 60.000000000000000 Hz
• Number of Poles: 1
• Type: Slide-to-off dimmer, single-pole
• Voltage Rating: 120
• Wattage: 1920.000000000000000 W
• Actuator: Slide
• Color: White
• Connection: Wire Leads
• Enclosure: Plastic
• Insulation: Plastic
• Material: Plastic/Metal
• Mounting: Wallbox
• Operating Temperature: 32 to 104 F
• Size: 4.56 x 2.75 in
