Specifications

• Height: 1.415 in | 35.941 mm
• Length: 3.072 in | 78.0288 mm
• Weight: 0.176 lbs
• Width: 1.394 in | 35.4076 mm

Additional Class Attributes

• Connection: Mechanical
• Contains DE-OX®: Yes
• Number of Conductors: 6
• Number of Poles: 1
• Number of Ports / Wireways: 6
• Number of Usable Ports: 6
• Number of Usable Taps: 6
• Replacement Part(s): PLUG-4

Dimensions

• Drive Size Main: 1/8
• Drive Type Main: Internal Hex
• Height BX (IN): 2.75
• Height (mm): 35.941
• Length (mm): 78.0288
• Max Insulation OD (IN): 0.317
• Max Insulation OD (mm): 8.0518
• Weight BX (LB): 1.221
• Width BX (IN): 5
• Width (mm): 35.4076

Additional Technical Specifications

• Conductor Type: Solid, Stranded

Material and Finish

• Conductor Material: Copper, Aluminum
• Connector Finish: Tin
• Insulation: Plastisol
• Material: Aluminum
• Wire Binding Hardware Finish: Zinc Clear Trivalent Chromate
• Wire Binding Hardware Material: Steel

Bolt and Screw Sizes

• Number of Wire Binding Screws per Port: 1
• Wire Binding Screw Size: 1/4
• Wire Binding Torque: 4 - 6 AWG = 35, 8 AWG = 25, 10 - 18 AWG = 20, 2 AWG = 40

Conductor Ranges

• Conductor Range AL Stranded (Primary, run, main, line): 4 Str - 14 Str
• Conductor Range CU Solid (Primary, run, main, line): 10 Sol - 14 Sol
• Conductor Range CU Stranded (Primary, run, main, line): 4 Str - 14 Str
• Conductor Range AL Solid (Primary, run, main, line): 10 Sol - 14 Sol

Voltage

• Voltage Rating: 600 V

Color

• Cap Color Main: Black
• Cap Color Tap: Black
• Color: Black

Testing Standards

• CSA File Number: LR-29601
• CSA Standard: C22.2 No. 65-03
• Prop65 Compliance: WARNING: Cancer and Reproductive Harm - www.P65warnings.ca.gov
• UL Control Number: 453G
• UL / CULUS Specification: UL 486A/B Listed
• UL File Number: E6207

General

• Bag Quantity: 1
• Carton Quantity Description: STD PACK QTY 6
• Dual Rated: Yes
• NEMA Code: S-588-4
• UPC Code: 78366907718

Environment and Temperature

• Environmental Conditions: Cold temperature rated to -45°C
• Flammability Rating: Insulation rated per UL 94
• Temperature Rating: 90°C
