Specifications

• Height: 1.863 in | 47.3202 mm
• Length: 8.014 in | 203.5556 mm
• Weight: 1.012 lbs
• Width: 1.965 in | 49.911 mm

Additional Class Attributes

• Connection: Mechanical
• Contains DE-OX®: Yes
• Number of Conductors: 10
• Number of Poles: 1
• Number of Ports / Wireways: 10
• Number of Usable Ports: 10
• Number of Usable Taps: 10
• Replacement Part(s): PLUG-3/0

Dimensions

• Drive Size Main: 1/4
• Drive Type Main: Internal Hex
• Height BX (IN): 2.75
• Height (mm): 47.3202
• Length (mm): 203.5556
• Max Insulation OD (IN): 0.62
• Max Insulation OD (mm): 15.748
• Weight BX (LB): 2.2711
• Width BX (IN): 6
• Width (mm): 49.911

Additional Technical Specifications

• Conductor Type: Stranded

Material and Finish

• Conductor Material: Copper, Aluminum
• Connector Finish: Tin
• Insulation: Plastisol
• Material: Aluminum
• Wire Binding Hardware Finish: Tin
• Wire Binding Hardware Material: Aluminum

Bolt and Screw Sizes

• Number of Wire Binding Screws per Port: 1
• Wire Binding Screw Size: 1/2
• Wire Binding Torque: 200

Conductor Ranges

• Conductor Range AL Stranded (Primary, run, main, line): 3/0 Str - 6 Str
• Conductor Range CU Stranded (Primary, run, main, line): 3/0 Str - 6 Str

Voltage

• Voltage Rating: 600 V

Color

• Cap Color Main: Black
• Cap Color Tap: Black
• Color: Black

Testing Standards

• CSA File Number: LR-29601
• CSA Standard: C22.2 No. 65-03
• Prop65 Compliance: WARNING: Cancer and Reproductive Harm - www.P65warnings.ca.gov
• UL Control Number: 453G
• UL / CULUS Specification: UL 486A/B Listed
• UL File Number: E6207

Environment and Temperature

• Environmental Conditions: Cold temperature rated to -45°C
• Flammability Rating: Insulation rated per UL 94
• Temperature Rating: 90°C

General

• Bag Quantity: 1
• Carton Quantity Description: STD PACK QTY 2
• Dual Rated: Yes
• NEMA Code: S-588-4
• UPC Code: 78366907778
