Features

• Compact Size Saves Space and Helps Reduce Overall Panel Size
• Interchangeable Lugs and Nut Keepers for Customer-Supplied Connections Allow for Last Minute Changes on Site
• Integral Din Rail or Base Mounting Capability Simplifies Mounting the Breaker without Having to Add Plates or Adapters
• Overcenter Toggle and Trip Free Mechanism
• Suitable for Reverse Feed Applications
• Common Trip
• RoHS Compliant

Additional Information

• Frame Type GB
• Size 2 Inch W x 2.71 Inch D x 5 Inch H

Specifications

• Type: Branch, Molded Case, Thermal and Fixed Magnetic
• Voltage Rating: 240 VAC, 480 Star/347 VAC, 600 Star/347 VAC at 50/60 Hz, 125/250 VDC (UL)
• Current Rating: 30 Ampere at 40 Deg C
• Number of Poles: 2
• Interrupting Rating: 100 Kiloampere at 240 VAC, 25 Kiloampere at 480 Star/347 VAC, 14 Kiloampere at 600 Star/347 VAC/125/250 VDC (UL)
• Installation: Bolt-On
• Application: Lighting, Distribution
• Used On: P1/P2/P3/P4/P5 Panelboard
• Approval: UL 489
• Series/Model: NGB
