Description
Features
- New and Improved Electronic
- 1/4 Inch More Wiring Bend Space than our Previous Design
- Both Lugs at the Same Angle for Easier Wiring
- Plug-In Branch Circuit Breakers for Murray Single Phase Load Centers
- LED Trip Indicator
- Reach Compliant
Additional Information
- Breaker Type MP-AT2
- Trip Indicator LED
Specifications
- Poles: 1
- Voltage Rating: 120 VAC
- Current Rating: 20 Ampere
- Interrupting Rating: 10 Kiloampere
- Terminal Type: Lug
- Wire Size: 14 to 8 AWG (Copper), 12 to 8 AWG (Aluminum)
- Application: HACR
- Construction Feature: Combination
- Mounting: Plug-In
- Used On: Loadcenter
- Size: 3.1 Inch W x 1.2 Inch D x 4.4 Inch H
- Approval: UL 1669
Downloads
Data SheetBrochure
More Information
Manufacturer Catalog Number
MPA120AFC
Weight
.3780
Applications
HACR
Current
20 amperes
Mounting Type
Plug-In
Product Size
1.2 inches
Voltage
120 volts
