Features

• Economical and Easy Installation saves on labor cost- 25% reduction of installation time and No Measurement of Material required
• Highly Intumescent
• Tested for PVC, CPVC, ABS and PVC/ABS Foam Core, FRPP, PP
• UL classified for both open and closed pipe systems and FBC System Compatible
• Fits in limited access areas

Applications

• Used to seal off plastic pipe both in closed & vented (DWV) conditions
• Collar may be used on up to 3 hour rated concrete floors and walls, up to 2 hour rated gypsum walls and up to 2 hour rated wood floors

Recommended Use

• PVC, CPVC, ABS, PVC foam core, ABS foam core, FRPP, PEX pipe, Electrical cable
• Also for use on up to 6" (152 mm) ABS (cellular/solid core), FRPP, PVC and CPVC pipe
• Not for use in environments with long-term exposure to rainfall/saltwater spray.
