Description
Specifications
- Height: 1.5 in
- Length: 5.5 in
- Weight: 1.132 lbs
- Width: 3.5 in
Additional Class Attributes
- Connection: Mechanical
- Contains DE-OX®: No
- Mounting Hole Type: Thru
- Number of Conductors: 3
- Number of Mounting Holes: 6
- Number of Poles: 1
- Number of Ports / Wireways: 3
Additional Technical Specifications
- Conductor Type: Stranded
Dimensions
- Dimension G (IN): 0.625
- Dimension G (mm): 15.875
- Drive Size Main: 1/2
- Drive Type Main: Internal Hex
- Height BX (IN): 2
- Mounting Bolt/Stud Size (mm): 304.8
- Mounting Hole Diameter (IN): 0.562
- Mounting Hole Diameter (mm): 14.2748
- Mounting Hole Spacing (IN): 1.75
- Mounting Hole Spacing (mm): 44.45
- Tang Length (IN): 3.25
- Tang Length (mm): 82.55
- Tang Thickness (IN): 0.375
- Tang Thickness (mm): 9.525
- Tang Width (IN): 3.5
- Tang Width (mm): 88.9
- Weight BX (LB): 1.2791
- Width BX (IN): 6.1875
Material and Finish
- Conductor Material: Copper, Aluminum
- Connector Finish: Tin
- Material: Aluminum
- Wire Binding Hardware Finish: Tin
- Wire Binding Hardware Material: Aluminum
Bolt and Screw Sizes
- Mounting Bolt/Stud Size: 1/2
- Number of Wire Binding Screws per Port: 2
- Wire Binding Screw Size: 13/16
- Wire Binding Torque: 500
Environment and Temperature
- Temperature Rating: 90°C
Conductor Ranges
- Conductor Range AL Stranded (Primary, run, main, line): 600 kcmil - 2 Str
- Conductor Range CU Stranded (Primary, run, main, line): 600 kcmil - 2 Str
Color
- Color: Silver
Voltage
- Voltage Rating: 35 kV
Testing Standards
- CSA File Number: LR-29601
- CSA Standard: C22.2 No. 65-03
- Prop65 Compliance: This product is in compliance with Prop65. It is not known to contain any chemicals associated with this regulation
- ROHS Indicator: IND
- UL Control Number: 453G
- UL / CULUS Specification: UL 486A/B Listed
- UL File Number: E6207
General
- Bag Quantity: 1
- Carton Quantity Description: STD PACK QTY 1
- Direct Burial: No
- Dual Rated: Yes
- NEMA Code: S-588-3
- UPC Code: 78366990057
Downloads
Spec SheetTechnical Drawing
T3AInformation Sheet
Form 1More Information
Manufacturer Catalog Number
T3A2-600N
Weight
1.279
Length
5.5
Width
3.5
Height
1.5
Material
Aluminum
Color
Silver
Carton Quantity
1
Conductor Material
Aluminum
Conductor Type
Stranded
Connection Type
Mechanical
Direct Burial (Y/N)
No
Mounting Hole Size
0.562 inches
Number Of Holes
6
Tang Length
3.25 inches
Tang Width
3.5 inches
Temperature Rating
90 degrees celsius
Voltage
35 volts
