Product Information

• Beam Angle (deg): 30
• Diameter (mm): 63.00
• Family Brand Name: Metalarc® Powerball
• Average Rated Life - Vertical (hr): 12000
• Diameter (in): 2.480
• Nominal Voltage (V): 90.00
• Base: E26 Medium
• Average Rated Life - (hr): 12000
• Bulb: PAR20
• Nominal Wattage (W): 39.00
• Approx. Lumens (initial - horizontal): 2000
• Color Temperature/CCT (K): 3000
• ANSI Code: C130/O
• Lamp Finish: Clear
• Abbrev. With Packaging Info.: MCP39PAR20U830FLPB 12/CS 1/SKU
• Average Rated Life - Horizontal (hr): 12000

Additional Product Information

Product Documents, Graphs, and Images

Packaging Information

• Case Depth (in): 4.563
• Case Weight (lbs): 3.984
• Pallet Qty: 1056
• Case Qty: 12
• SKU Qty: 1
• SKU's/Pallet: 1056
• SKU UPC: 046135642654
• Cases/Pallet: 88
• Case Cube (ft): 0.214
• Case Length (in): 10.313
• Case Width (in): 7.874
• SKU's/Case: 12

Footnotes

• The circuit must include overcurrent protection (I.e. Thermally switched ballast).
• Use with 4000V pulse rated sockets only.
• O = Lamps classified as O-type, comply with ANSI standard C78.389 for containment testing and may be used in open luminaries. See lamp warning.
• Lamp requires a nominal Open Circuit Voltage of 230V or higher. Without an ignitor in the circuit minimum OCV is 209Vrms.
• UV-Stop quartz
• Consult your OSRAM SYLVANIA Lighting Representative for compatible electronic operating systems.
• Approved electronic ballast is required, view approved ballast list in Product documents, graphs and images.
