Features

• Eco-Friendly - The byproducts of zinc casting can be melted down and recast to make new metals without property degradation
• Grounded & Insulated - The tin-plated aluminum alloy 6061-T6 grounding lug provides maximum precipitation hardening and the UV-stabilized nylon insulator lining prevents damage to the wire
• Might-Rite® Patented Design - The Might-Rite split design, available with stainless steel hardware and UV-stabilized insulators, makes positioning easy to save time and money on expensive rework
• Professional Performance - All Bridgeport fittings meet OSHA-recognized, NRTL-listed electrical standards and meet the stringent bonding and grounding requirements of 514B and 467 cULus

Specifications

• Country of Origin: China
• Length: 4.08 in
• Width: 4 in
• Depth: 2.49 in
• Weight: 14.03 lbs
• BPT Trade Size: 3"
• COLOR: Grey with Black Insulator
• Field Application: Used in situations where wires have already been pulled through conduit or EMT fittings, and an insulated Grounding bushing is required. Grounding lug; aluminum alloy 6061-T6. Rated 150 Degree C. cULus listed to UL514B and UL467 specifications. Patented. All Zinc Die Cast Mighty-Rites are now available with Stainless steel hardware and UV stabilized insulators, for use in outdoor applications.
• FINISH: Ball Burnished, Mirror Smooth, Grounding lug: Tin Electro-plate
• MATERIAL: Zinc Die Cast
• NEMA Rating: FB-1
• UL File #: E20412
• WARRANTY: 1 Year
