Features

• Impact Resistant - The natural strength, rigidity, and ductility of malleable iron provides the ability to flex without breaking, offering the highest protection from physical damage caused by crushing or abrasion
• Zinc-Plated - Zinc-plating adds a cost-effective and strong protective layer that provides extended corrosion resistance
• Heat Rating - The bushing is temperature rated to 150°C for use in industrial environments
• Grounded & Insulated - The tin-plated aluminum alloy 6061-T6 grounding lug provides maximum precipitation hardening and the plastic metaliner prevents damage to wire insulation
• Professional Performance - All Bridgeport fittings meet OSHA-recognized, NRTL-certified electrical standards and meets the stringent bonding and grounding requirements of 514B cULus

Certifications and Standards

• UL-514B

Specifications

• Country of Origin: China
• Length: 4 in
• Width: 1 in
• Weight: 84.9 lbs
• BPT Trade Size: 3"
• COLOR: Grey with Black Insulator
• Field Application: For use on threadless rigid and IMC conduit where an insulated grounding bushing is required. Rated 150 Degree C. cULus listed. Patented
• FINISH: Zinc Plated, Grounding Lug: Tin Electro-plate
• MATERIAL: Malleable Iron
• NEMA Rating: FB-1
• UL File #: E20412
