In-Sure® Push-In Wire Connector, Model 34 4-Port Yel, Box of 100
In-Sure® Push-In Wire Connector, Model 34 4-Port Yel, Box of 100
Total Price: $0.18 per each Sold in increments of 100 each
Description
Features
- Ergonomic design for easy grip and comfortable installation
- Low insertion force for fast and easy connections
- Compact size makes installation easy
- Clear shell gives visual verification of connection
- Tough, UL 94V-2 flame-retardant shell rated at 105°C (221°F)
- Approved for bonding and grounding applications
Downloads
Spec SheetPDF Instructions
P-2854_In-SurePush-inSS.pdf
WireTermination_LimitedWarranty.pdf
WireConnector_Catalog.pdf
More Information
Manufacturer Catalog Number
30-1034
Weight
.0051
Color
Yellow
Product Size
0.780 IN Length X 0.820 IN Width X 0.380 IN Height
Temperature Rating
105 DEG C Shell Rated
Type
Push-In
Wire Length
Wire Size
#12 AWG - #20 AWG Solid, #12 AWG - #16 AWG (19 Strand Or Less) #18 AWG (7 Strand) Stranded, #14 AWG - #18 AWG (19 Strand Or Less) Stranded (Tin Bonded)
