Features

• Insulating Liner Material is Self-Extinguishing
• The Plastic Liner is Tough, it Won't Chip, Crack, Swell or Shrink
• Liner Resists Corrosion, Chemicals and Temperature Extremes
• Surface Friction is So Low that Wires can be Pulled with Virtually No Abrasion on the Cable Insulation

Additional Information

• Applicable Standard W-F-408E, NEMA FB-1
• Temperature Rating 150 Deg C

Specifications

• Type: Threadless Set Screw
• Trade Size: 1 Inch
• Wire Size: 14 to 4 AWG
• Lug Type: Lay-In, Tin Plated Aluminum
• Conductor Material: Copper/Aluminum
• Throat Type: Insulated
• Diameter: 1-3/4 Inch
• Height: 9/16 Inch
• Material: Zinc Plated Malleable Iron Body, Zinc Plated Steel Set Screw, Zinc Plated Steel Clamping Screw
• Approval: UL 467, CSA C22.2
• Used On: Rigid Conduit/IMC
• Series/Model: IBC-LS-AC
