Specifications

• Country of Origin: United States
• Color Code - Side A: Green
• Color Code - Side B: Green
• Conductor - AL Str Size A: 8 AWG
• Conductor - AL Str Size B: 8 AWG
• Conductor - Copper Solid Size A: 6 AWG
• Conductor - Copper Solid Size B: 6 AWG
• Conductor - Copper Str Size A: 8 AWG
• Conductor - Copper Str Size B: 8 AWG
• Dimension - B Length inch: 0.87 in
• Dimension - L Length Overall mm: 51 mm
• Dimension - Length Overall inch: 2 in
• Dimension - Outside Diameter inch: 0.65 in
• Plated: Y
• Plating Type: Tin - Hot Dipped
• Prefilled Oxide Inhibitor: Y
• Product Type: Compression
• Standards - RoHS Compliance Status: CM
• Trade Name: LINKIT™
• Type: Service Entrance, Uninsulated, Center Stop
• Certification Agency: Proposition 65
• Class Code: B30
• Freight Class Code: 16027000
• Harmonization Code: 8535908020
• Image Actual Or Representative: A
• Lead Time: 12 wk
• Sub Class Code: B30B3VF
• Die Index: 243;BG or 5/8
• UL Listed: No
• Material: Aluminum
• Base Unit of Measure: EA
• BOX SIZE: 5.125x7.373x6.438 (in)
• Carton - Gross Weight per Pack: 6.000 lb.
• Carton - Number of Sub Packs: 100
• Carton - Pack Description: Carton
• Carton - SCC-14 Next Lower Level Sub Pack: 00781810143148
• Carton - Total Units: 100
• Case - SCC-14 Next Lower Level Sub Pack: 30781810143149
• Package - GTIN - Package: 30781810143149
• Package - Total Units: 100 EA
• Package Quantity: 100 EA
• Package Weight: 0.000 lb.
• Pallet - GTIN - Package: 70781810143147
• Pallet Height: 46.750 in
• Pallet Length: 48.000 in
• Pallet Weight: 1821.000 lb.
• Pallet Width: 40.000 in
• Standard Package Quantity: 100

Certifications

• CSA Approved: No
• cULus: No
• ETL: No
• UL Recognized: No
