Description
Features
- For support when cable end is not available
- Split Mesh- Rod Closing
Specifications
- Country of Origin: Mexico
- Approx Breaking Strength: 300 lb.
- Cable Diameter Range: 0.23 in-0.32 in
- Width: 5.000 in
- Each - Width: 5.000 in
- Industry Standard(s): CSA Certified
- Application: Single Eye
- Cable Size: .23"-.32" (.58-.81)
- Special Features: Split Mesh- Rod Closing
- Standard: CSA Certified
- Type: Single Eye
- Style: Split Mesh, Rod Closing, Single Weave
- Class Code: A52
- Description - Invoice: FO SGL EYE SUP GRIP, .23"-.32"; ROD
- Freight Class Code: 06168002
- Harmonization Code: 7419805050
- Image Actual Or Representative: A
- MSDS Flag: No
- Replaced Catalog Number: HPW022291017
- Sub Class Code: A52A480
- Material - Mounting Hardware: Screw Hook or Beam Clamp
- Construction: Woven
- Material: Bronze, Tin Coated
- Series: Fiber Optic
- Base Unit of Measure: EA
- BOX SIZE: 7.900x9.000x5.100 (in)
- Carton - SCC-14 Next Lower Level Sub Pack: 00783585497945
- Case Weight: 1.300 lb.
- Each - Pack Description: Each
- Lowest Level UOM: Each
Certifications
- EU RoHS Indicator: Yes
Downloads
Spec SheetCatalog Full Asset Reference
Catalog Page Asset Reference 1
Catalog Page Asset Reference 2
Installation Manuals Asset Reference
Sales Drawing Asset Reference
Warranty Document Asset Reference
Pulp & Paper Solutions
PULP & PAPER SOLUTIONS
FOOD & BEVERAGE SOLUTIONS
Videos
More Information
Manufacturer Catalog Number
022291017
Weight
.0500
Width
5.000
Country of Origin
Mexico
Material
Bronze
