Product Information

• Nominal Wattage (W): 75.00
• Color Rendering Index (CRI): 87
• Average Rated Life (hr): 12000
• Base: Single Pin
• Actual Length (mm): 2387.60
• Diameter (in): 1.593
• Color Temperature/CCT (K): 4100
• Nominal Length (in): 96.000
• Mean Lumens at 35C: 3872
• Nominal Length (mm): 2438.40
• Abbrev. With Packaging Info.: F96T12CWX 15/CS 1/SKU
• Bulb: T12
• Actual Length (in): 94.000
• Initial Lumens at 25C: 4400
• Diameter (mm): 40.46

Additional Product Information

Product Documents, Graphs, and Images

Packaging Information

• Case Width (in): 5.180
• Cases/Pallet: 45
• Case Qty: 15
• Case Depth (in): 95.250
• Pallet Qty: 675
• SKU Qty: 1
• SKU UPC: 046135294785
• SKU's/Case: 15
• SKU's/Pallet: 675
• Case Weight (lbs): 21.500
• Case Length (in): 8.810
• Case Cube (ft): 2.516

Footnotes

• Minimum starting temperature is a function of the ballast; consult the ballast manufacturer.
• Approximate initial lumens after 100 hours operation.
• Average life rating at 12 hours operation per start is 18,000 hours.
• The life ratings of fluorescent lamps are based on 3 hr. burning cycles under specified conditions and with ballast meeting ANSI specifications. If burning cycle is increased, there will be a corresponding increase in the average hours life.
