Features

• Continuous, flicker-free dimming from 100% to 1% or less for T8, and 1% for T5 and T5HO lamps.
• Compatible with Energi Savr Node with EcoSystem unit, GRAFIK Eye QS control unit, PowPak dimming module with EcoSystem unit, and Quantum software, allowing for integration into an existing or planned EcoSystem lighting control solution.
• Programmed rapid start design preheats lamp cathodes before applying full arc voltage to ensure full-rated lamp life while dimming and cycling.
• Lamps turn on to any dimmed level without going to full brightness.
• Low harmonic distortion throughout the entire dimming range maintains power quality.
• Frequency of operation ensures that ballast does not interfere with infrared devices operating between 38 kHz and 42 kHz.
• Ballasts maintain consistent light output for different lamp lengths, ensuring fixture-to-fixture uniformity.
• Ultra-quiet operation.
• Ballast protected from miswires of any input power to control lead, or from lamp leads to each other and/or ground.
• End-of-lamp-life protection circuitry ensures safe operation throughout entire lamp life.
• Digitally addressable ballasts that provide a low-cost, flexible solution for any space in any application
• Industry leading, continuous, flicker-free dimming from 100 to 1 % or less to meet the needs of the most demanding applications
• Individual control with the EcoSystem Digital Link eliminates the need to rewire, reduces design time, and provides a scalable solution from a small area to an entire building
• Compatible with Energi Savr Node with EcoSystem and Grafik Eye QS control units, PowPak dimming module with EcoSystem units, and Quantum software, allowing for integration into an existing or planned EcoSystem lighting control solution
• Programmed rapid start design preheats lamp cathodes before applying full arc voltage to ensure full-rated lamp life while dimming and cycling
• 100 % performance tested and burned in at factory
• Lamps turn on to any dimmed level without going to full brightness
• Low harmonic distortion throughout the entire dimming range maintains power quality
• Frequency of operation ensures that ballast does not interfere with infrared devices operating between 38 and 42 kHz
• Maintains consistent light output for different lamp lengths, ensuring fixture-to-fixture uniformity
• Ultra-quiet operation
• Protected from miswires of any input power to control lead, or from lamp leads to each other and/or ground
• End-of-lamp-life protection circuitry ensures safe operation throughout entire lamp life
• Non-volatile memory restores all ballast settings after power failure
• 100 % compatible with all EcoSystem digital controls
• Custom ballast factors available for UL or CSA listed products
• Design tool and specifications can be found at www.lutron.com/ballasttool.

Standards and Certifications

• UL
• CSA
• ISO
• Class P thermal protected
• ANSI
• FCC

Specifications

• Amperage Rating: 0.29@120 V/0.14@240V/0.12@277V
• Application: Lighting Control
• Ballast Factor: 1
• Color: White
• Frequency Rating: 50/60 Hz
• Height: 1 in
• Lamp Type: T8/U-Bend fluorescent
• Length: 14.13 in
• Minimum Starting Temperature: 50 F
• Mounting: Fixture
• Number Of Lamps: 1
• Power Factor: Greater than 0.95
• Start Type: Programmed rapid
• Thermal Protection: Class P
• Total Harmonic Distortion: Less than 10%
• Type: Ballast
• Voltage Rating: 120/240/277 V
• Wattage: 32 W
• Width: 1.18 in
