Features

• Provides high-performance dimming for any compact fluorescent application
• Offers continuous flicker-free dimming from 100% to 5 %, providing both energy savings and lighting flexibility
• Compatible with Energi Savr Node with EcoSystem devices, GRAFIK Eye QS with EcoSystem connection, PowPak dimming module with EcoSystem connection, and Quantum systems, allowing for integration into an existing/planned EcoSystem lighting control system
• Supports standard 3-wire line-voltage phase control technology
• Programmed rapid start design ensures full-rated lamp life while dimming and cycling
• Lamps turn on to any dimmed level without flashing to full brightness
• Low harmonic distortion throughout the entire dimming range
• Frequency of operation ensures that ballast does not interfere with infrared devices
• Inrush current limiting circuitry eliminates circuit breaker tripping, switch arcing, and relay failure
• Ultr-quiet operation
• Protected from miswires of any input power to control lead, or from lamp leads to each other and/or ground
• End-of-lamp-life protection circuitry ensures safe operation throughout entire lamp life
• Nonvolatile memory restores all ballast settings after power failure
• 100% compatible with all Lutron 3-wire fluorescent controls and EcoSystem digital controls
• 100% performance tested at factory
• Custom ballast factors available
• Design tool and specifications can be found at www.lutron.com/ballasttool

Standards and Certifications

• UL
• CSA
• ISO
• Class P thermal protected
• ANSI
• FCC

Specifications

• Amperage Rating: 0.36@120 V/0.20@220V/0.18@240V/0.15@277V
• Application: Lighting Control
• Ballast Factor: 0.95
• Color: White
• Dimmable: Dimmable
• Frequency Rating: 50/60 Hz
• Height: 1.29 in
• Lamp Type: T4 4-Pin Triple tube Fluorescent
• Length: 4.9 in
• Minimum Starting Temperature: 50 F
• Mounting: Fixture
• Number Of Lamps: 1
• Power Factor: Greater than 0.95
• Start Type: Rapid
• Thermal Protection: Class P
• Total Harmonic Distortion: Less than 10%
• Type: Ballast
• Voltage Rating: 120/220/240/277 V
• Wattage: 42 W
• Width: 3 in
