Description
Specifications
- Height: 14.38 IN
- Length: 7.38 IN
- Width: 8.69 IN
- Weight: 9 LB
- Type: Non-fusible, single-throw
- Amperage Rating: 60A
- Enclosure: NEMA 3R, Rainproof
- Enclosure Material: Painted galvanized steel
- Fuse Configuration: Non-fusible
- Number Of Poles: Two-pole
- Number Of Wires: Two-wire
- Product Category: General duty safety switch
- Voltage Rating: 240V
- Notes: WARNING! Switch is not approved for service entrance unless a neutral kit is installed.
Downloads
idcplg.pdfDG222URB.a
More Information
Manufacturer Catalog Number
DG222URB
Weight
9.0000
Amperage
60 amperes
Number Of Poles
2
Number Of Wires
2
Type
Non-fusible, Single-throw
Voltage
240 volts
