Features

• Includes (1) 3-speed fan switch; Gloss finish
• No Neutral Required; 120V
• Rated up to 2.0 Amp of indoor ceiling paddle fans
• One (1) ceiling paddle fan only per fan control; not compatible with fans with proprietary remotes or DC motors
• 3-way compatible with existing switches
• Wire-lead connections
• Large paddle switch turns fan on and off to preset level and slider adjusts fan speed
• Provides 3 quiet fan speeds for comfort
• Fits large designer-style openings; Available in in 7 gloss colors
• Pairs perfectly with Lutron Claro wall plates for consistent color matching (sold separately)
• Controls 2 A fan
• Paddle turns on/off
• Slide up to increase speed, down to decrease speed
• 3 quiet fan speeds for increased comfort
• For use with only one ceiling paddle fan
• Does not include locator light
• Designed to prevent motor hum.

Standards and Certifications

• UL
• CUL
• cUL

Specifications

• Actuator: Paddle switch
• Amperage Rating: 2 A
• Application: Fan Control
• Color: Light Almond
• Connection: Wire leads
• Contact Configuration: N-O
• Contact Rating: 2 A
• Enclosure: Plastic
• Mounting: Wallbox
• Number Of Poles: 1
• Size: 4.69 x 2.94 in
• Type: Fan control for use with Hunter original series fans, 3-way/single-pole
• Voltage Rating: 120 V
• Wattage: 240 W
