Specifications

General

• Application: For Higher Voltage Applications From 5 KV Through 35 KV
• Color Code: Pink
• Connector Type: Splice
• Feature - Barrel Style: Tapered
• Feature - Barrel Type: Standard
• Material: Copper
• Plated: Y
• Plating Type: Electro Tin plated
• Sub Brand: HYLINK
• Trade Name: HYLINK™
• Type: YSP-T, High Voltage, Long Barrel
• UPC: 781810501023

Dimensions

• Dimension - B Length inch: 1.11 in
• Dimension - L Length Overall mm: 55 mm
• Dimension - Length Overall inch: 2.15 in
• Dimension - Strip Length inch: 1-3/32 in

Conductor Related

• Conductor - Copper Str Size: 1/0 AWG

Certifications and Compliance

• Certification - CSA Approved: Yes
• Certification - ETL: No
• Standards - RoHS Compliance Status: CM
• UL Listed: Yes

Logistics

• Minimum Pack Quantity: 1
