Features

• Nominal .002 inch (2 mil) blue urethane coating on interior and exterior
• Minimum .040 inch (40 mil) PVC coating is bonded to the exterior
• Straight threads (NPS)
• Molded ribs on outer coating for easy installation, up to and including 4 inch
• Pressure sealing sleeves protect your connection

Specifications

North American Specifications (UNSPSC)

• UNSPSC: 39131707 Electrical conduit coupling
• IGCC: 5548 Electrical conduit coupling
• Brand Name: Ocal
• Type: Conduit Coupling
• Special Features: Pressure-Sealing Sleeves Protect Your Connection
• Application: Corrosion-Protected Connections for Conduit Sections
• Trade Size: 3/4 Inch/21mm
• Length: 3.75 in ; 95.25 mm
• Material: Aluminum
• Color: Gray

European Specifications (ETIM)

• ETIM: EC000939 Coupler for installation tubes
• Material: Metal
• Material quality: Aluminium
• Surface protection: Untreated
• Model: Thread
• For nominal tube diameter: 21mm
• Two piece: N
• With inspection opening and cover: N

Packaging

• Inner Dimensions (inches): xx
• Outer Quantity: 90
• Outer Dimensions (inches): 16.5x13.75x7.75
• Weight Uom: 0.15 lbs. Each
