Features

• Smooth throats for easy wire pulling
• Spacious, accessible wiring chamber provides a convenient location to pull conductors and make splices.
• Retained stainless steel cover screws

Application

• For use with rigid/IMC conduit
• Threaded conduit bodies maintain a weather resistant conduit system when used with covers and gaskets.

General

• Material: Die Cast Aluminum
• Volume (cu.in.): 11.8
• Trade Size (inches): 1

Dimension Information

• E (inches): 3 1/2
• D (inches): 1 7/8
• A (inches): 5 3/8
• B (inches): 5 15/16
• F (inches): 2 5/8
• G (inches): 1
• C (inches): 1 3/4

Accessories & Components

• Gasket-Composition: GKV-3
• D-Pak Catalog Number: DAT-3-CG
• Cover-Stamped Aluminum: SCV-3
• Cover-Die Cast: CV-3
• Gasket-Neoprene: GKN-3

Packaging

• Outer Package: 25
• Package Length: 14.3
• Inner Package: 5
• Order Multiple: 5
• T&B Sold in UOM: Each
• Package Width: 8.9
• Package Height: 11.9
• T&B Weight Per UOM: 0.64 lbs. Each

Application Support

Certifications

• UL
• RoHS Compliance: Yes
