Features

• No tools needed to assemble to end of cable or install into box or enclosure
• Preassembled anti-short bushing will not fall out during installation
• Easy installation - push the cable into the fitting, push connector into the box or enclosure
• Can be removed without tools and is reusable
• Rugged one piece design
• Made from steel and nylon (bushing)
• Zinc electroplated for corrosion protection
• Tri-linigual (English, Spanish and French installation instructions included in each unit carton)
• UPC bar coded fittings are individually polybagged with a preprinted UPC-A bar code and packaged in pre-scored tear top cartons for an attractive presentation
• Additional sizes available

Specifications

General

• Conduit Type: Armored Cable/Metal Clad (AC/MC)
• Fitting Type: Connectors
• Material: Steel
• UPC: 050169999998

Dimensions

• Height: 0.84 in
• Length: 1.07 in
• Trade Size: 1/2 in
• Weight: 0.035 lb
• Width: 0.84 in

Conductor Related

• Cable Size: MCI: Steel/AL .475 - .575; MCI-A: AL .430 - .560; MCI-A: Steel .470 - .540; AC: Steel/AL 14-2 to 12-4 (.475 - .575)

Certifications and Compliance

• Certified Listed: UL Listed

Logistics

• Carton Quantity: 500 EA
• Pallet Quantity: 32000 EA
