Specifications

• Length: 9.650000000 IN
• Width: 6.300000000 IN
• Height: 5.910000000 IN
• Weight: 4.060000000 LB
• Adjustment range undelayed short-circuit release: 1000 A
• Complete device with protection unit: true
• Degree of protection (IP): IP40
• Device construction: Built-in device fixed built-in technique
• DIN rail (top hat rail) mounting optional: false
• Integrated earth fault protection: false
• Motor drive integrated: false
• Motor drive optional: true
• Number of auxiliary contacts as change-over contact: 0
• Number of auxiliary contacts as normally closed contact: 0
• Number of auxiliary contacts as normally open contact: 0
• Number of poles: 2
• Overload release current setting: 200 A
• Position of connection for main current circuit: Other
• Rated permanent current Iu: 200 A
• Rated short-circuit breaking capacity lcu at 400 V, 50 Hz: 55 kA
• Rated voltage: 690 V
• Suitable for DIN rail (top hat rail) mounting: false
• Type of control element: Rocker lever
• Type of electrical connection of main circuit: Other
• With integrated under voltage release: false
• With switched-off indicator: false
