BRKR 3VA41 2P 20A 65KA Molded Case Circuit Breaker

This Siemens 3VA41 molded case circuit breaker is designed for low voltage electrical distribution and protection. It features a thermal-magnetic trip unit suitable for reliable overload and short-circuit protection, making it ideal for use in lighting solutions, wire and cable systems, and as part of switchgear assemblies. The breaker is naval rated for 50°C operation and includes load side installed lugs for secure connections.

Specifications

• Manufacturer: Siemens
• Manufacturer Part #: 3VA4120-6ED24-1AA0
• Frame: 3VA41
• Current Rating: 20A
• Number of Poles: 2
• Breaking Capacity: 65kA at 480V, 25kA at 600Y/347V
• Trip Unit: Thermal-Magnetic TM210 with fixed Ir and Ii
• Dimensions (W x H x D): 5.31 in x 2.28 in x 6.61 in
• Weight: 1.31 lbs
• Naval Rated: Yes, 50°C
• Lugs: Installed in load side only

Features

• High (Class H) breaking capacity for enhanced protection
• Thermal-magnetic trip unit for precise overload and short-circuit response
• Compact dimensions suitable for various electrical distribution panels
• Naval rating ensures suitability for marine and harsh environments
• Load side lug installation simplifies wiring and maintenance
