Features

• Hassle-free, automatic measurement of amperage, voltage and resistance
• Low impedance eliminates stray or "ghost" voltage readings
• True RMS for the most accurate measurement when harmonics are present
• High resolution, auto-illuminating LCD backlit display
• Auto off for longer battery life
• Resistance measurement
• Audible continuity test
• CAT IV, 600 V

Application

• Electrical

Included Components

• (1) 9 V Battery, Test Leads, Carrying Case

Prop 65 Warning

• Di(2- ethylhexyl)phthal ate (DEHP)

Specifications

• Country of Origin: Taiwan
• Amperage Measurement: AC A 0.9 to 600.0
• Display: LCD, 10000 Count
• Includes: (1) 9 V Battery, Test Leads, Carrying Case
• Jaw Opening: 1.340 IN
• Measurement Category: CAT III, 1000 V
• Operation Type: Automatic
• Replacement Part: TSG-3 Test Leads, TC-10 Carrying Case
• Resistance Measurement: 999Ω, 9.999kΩ
• Standard: CAT IV, C/US UL Listed, CAT III
• Type: Electrical
• Voltage Measurement: AC V - 1.3 to 999.9 VAC
• DC V: 2.1 to 999.9; -0.7 to -999.9

Regulations

• CA Prop 65 Cancer: Yes
• CA Prop 65 Reproductive Harm: Yes
• CA Prop 65 Chemcial Names: Di(2- ethylhexyl)phthal ate (DEHP)
