Features

• Locking Screw and Slot Prevents Plug Cable Collar from "Backing Off"
• Controlled Length Contacts Ensure that Ground Makes First and Breaks Last for Added Safety
• Contacts Exert Constant Pressure Along Entire Contact Surface and Provide Electrical Continuity
• Insulating Blocks Provide Greatest Di-Electric and Mechanical Strength and Lowest Arc Tracking
• Neoprene Bushing Compressed by Cable Collar Prevents Entrance of Water Bushing is Highly Resistant to Hydrocarbon Deterioration and is Self-Extinguishing

Additional Information

• Enclosure NEMA 3/4/4X
• Finish Fiberglass Reinforced Polyester (Insulating Block)
• Operating Temperature Rating -13 to 104 Deg F
• Applicable Standard NEC/CEC

Specifications

• Type: Positive Polarization, Locking Screw, Reverse Service
• Voltage Rating: 600 Volt AC 50/400 Hertz, 250 Volt DC
• Current Rating: 200 Amp
• Number of Poles: 3
• Number of Wires: 4
• Grounding Style: Shell, Extra Pole, 2
• Minimum Cable Outer Diameter: 1.875 Inch
• Maximum Cable Outer Diameter: 2.5 Inch
• Material: Epoxy Powder Coated Copper-Free Aluminum
